Ermenrich Seek DS20 Digital Sound Level Meter

The price is valid only for the online store and may differ from the prices in retail stores.

Functions: sound level meter, hygrometer, thermometer

Thermometer, hygrometer, sound level meter

Data and parameters measured by the device

30–130dB

Measuring range that the device can capture

Monochrome

The screen type influences readability under different lighting conditions

Availability

Product ID	82994
Brand	Ermenrich
Warranty	5 years
EAN	5905555017730
Package size (LxWxH)	7.1x3.5x2.4 in
Shipping Weight	0.5 lb

Description

The Ermenrich Seek DS20 is a multifunctional device that allows you to measure noise levels, humidity, and temperature both indoors and outdoors. It can be used to monitor conditions in residential, office, or industrial spaces, thereby checking their compliance with the standards.

The sound level meter quickly and accurately measures noise levels in the range of 30–130dB. In addition, the device determines air temperature in the range of −20°C to 60°C, humidity in the range of 0% to 99.9%. There are functions for holding data and storing the limit values.

The device requires 3 AAA batteries to operate (not included). To save battery power, the sound level meter automatically turns off after 10 minutes of inactivity. If necessary, you can disable this option. In addition to displaying measurement data on the screen, there is a battery charge level indicator.

Key features:

Measurement of noise, temperature, air humidity, dew point
Holding the current readings, storing the limit values
Monochrome screen, analog sound pressure bar
Powered by standard batteries, auto-off function, charge level indicator

The kit includes:

Digital sound level meter
Pouch
User manual and warranty card

specifications

Product ID	82994
Brand	Ermenrich
Warranty	5 years
EAN	5905555017730
Package size (LxWxH)	7.1x3.5x2.4 in
Shipping Weight	0.5 lb
Type	sound level meter
Built-in features	thermometer, hygrometer, sound level meter
Hygrometer (air humidity)
Units of measurement	% (RH)
Measuring range	from 0% to 99%
Accuracy	±3% in the range of 20% to 80%; ±4% in other ranges
Thermometer (temperature)
Units of measurement	°C, °F
Measuring range	−20°C to +60°C (−4 to +140°F)
Wet bulb measuring range	−20°C to +60°C (−4 to +140°F)
Dew point measuring range	−50°C to +60°C (−58 to +140°F)
Accuracy	±1°C in the range of 0°C to 45°C/±2°F in the range of +32 to +113°F; ±1.5°C/±3°F in other ranges
Sound level meter (noise)
Units of measurement	dB
Measuring range	30–130dB
Accuracy	±15dB (94dB@1kHz); ±5dB (94dB@8kHz)
Frequency range, Hz	30 Hz–8 kHz
Weighing properties	A/C
Dynamic characteristics	125ms (fast), 1s (slow)
Special features	analog sound pressure bar, out-of-range alerts (UL/OL)
General specifications
Hold function	✓
Limit value function (Min/Max)	✓
Display	monochrome
Low battery status indicator	✓
Power supply	3 AAA batteries (not included)
Auto power off	✓
Safety standards	EN61326-1

References
and downloads

Ermenrich Measuring Tools (pdf)

(PDF, 1.07 Mb)

User manual: Ermenrich Seek DS20 digital sound level meter (pdf)

(PDF, 956.12 Kb)
