UA Levenhuk M130 BASE Digital Camera
A modern microscope digital camera
| Product ID | 70353 |
| Brand | Levenhuk, Inc., USA |
| Warranty | lifetime |
| EAN | 5905555003399 |
| Package size (LxWxH) | 2.4x5.5x3.5 in |
| Shipping Weight | 0.4 lb |
The Levenhuk M130 BASE Digital Camera was designed specifically for microscopes. It allows taking photos and videos and transferring pictures to a computer screen. The camera will be a capable assistant in micro-research; with its help, you will be able to create photo archives of the observations and record educational videos. The Levenhuk M130 BASE digital camera is an excellent choice for presentations and lectures at schools. It is also suitable for home use.
This 1.3Mpx camera allows you to take pictures with a resolution of 1280x1024 pixels. The maximum frame rate is 12.5fps. To select an appropriate shooting mode, connect the camera to your computer via USB cable, and install the software that is included in the package. This special software allows you to choose the resolution of the video, crop pictures, and adjust brightness and contrast.
The Levenhuk M130 BASE Digital Camera can be installed on a biological or stereoscopic microscope. The camera is compatible with 23.2mm diameter eyepiece tubes. For ocular tubes of other diameters, you can use special adapters (sold separately).
The kit includes a CD with special software that allows you to edit previously saved images: zoom them, crop them, change the contrast, and so forth.
To ensure the best possible performance of your new camera, make sure your computer complies with the system requirements specified by the manufacturer. Compatible OS include Mac, Linux, and Windows. A USB 2.0 port is required to establish a connection. If the software does not run on your computer, please contact us and specify your operating system and its version (for Linux: platform and kernel version).
The latest version of Levenhuk Software for Windows supports eight languages: English, French, German, Polish, Russian, Simplified Chinese, Traditional Chinese, Turkish.
The kit includes:
- Levenhuk microscope digital camera
- USB cable for connection to PC or laptop and power supply
- Installation CD with Levenhuk image editing software and the required drivers
- User manual and lifetime warranty
| Product ID | 70353 |
| Brand | Levenhuk, Inc., USA |
| Warranty | lifetime |
| EAN | 5905555003399 |
| Package size (LxWxH) | 2.4x5.5x3.5 in |
| Shipping Weight | 0.4 lb |
| Sensor | CMOS |
| Megapixels | 1.3 |
| Maximum resolution, pix | 1280x1024 |
| Sensor size | 1/3" |
| Pixel size, μm | 3.6x3.6 |
| Exposure time | auto |
| Video recording | ✓ |
| Frame rate, fps at resolution | 7.5@1280x1024, 12.5@1024x768, 12.5@800x600 |
| Place of installation | eyepiece tube of 23.2mm diameter, instead of the actual eyepiece |
| Image format | *.jpg, *.bmp, *.png, *.tif |
| Video format | output: *.wmv, *.avi, *.h264 (Windows 8 and later), *h265 (Windows 10 and later) |
| Spectral range, nm | 380–650 (built-in IR filter) |
| Shutter type | ERS (electronic rolling shutter) |
| White balance | manual, automatic |
| Exposure control | manual, automatic |
| Software features | image size, brightness, exposure time |
| Output | USB 2.0, 480 Mbps |
| System requirements | Windows 8/10/11 (32bit and 64bit), Mac OS X, Linux, up to 2.8GHz Intel Core 2 or higher, minimum 2GB RAM, USB 2.0 port, CD-ROM |
| Software | Levenhuk |
| Body | metal |
| Power supply | 2.0 USB cable |
| Operating temperature range, °F | 14...+122 |
Thank you for your request.
We do not sell these adapters separately, but such adapters are included with the Levenhuk M PLUS series, which you may purchase from Amazon:
https://www.amazon.co.uk/Levenhuk-M1000-PLUS-Digital-Camera/dp/B073RVBLZZ?ref_=ast_sto_dp&th=1
In case you only need an adapter - there are many of them available on Amazon. Just type in "microscope camera adapter".
Is there any additional information you might need?
