MAGUS MCD20 LCD Monitor
13.3", IPS, 1920x1080px (Full HD), HDMI
IPS
Matrix type is a key element of the screen responsible for displaying the image
13.3
Display diagonal
1920x1080 (Full HD)
The display resolution is the number of pixels horizontally and vertically
Product ID | 83210 |
Brand | MAGUS |
Warranty | 5 years |
EAN | 5905555019321 |
Package size (LxWxH) | 13.8x9.4x2.4 in |
Shipping Weight | 2.8 lb |
Description
MAGUS MCD monitors work in combination with MAGUS CHD cameras to form a complete imaging system for MAGUS microscopes.
The MCD20 model reproduces the image in Full HD resolution and is recommended for MAGUS cameras:
- CHD10
- CHD20
- CHD30
The connection to the camera occurs via its HDMI interface. The monitor displays real-time images. Its IPS LCD display has a wide viewing angle, high brightness, and good contrast. When looking at the screen even from a large angle, the image is not distorted. The screen size is 13.3''.
The monitor can be installed on a horizontal surface using a folding stand or mounted directly on a camera or tripod.
specifications
Product ID | 83210 |
Brand | MAGUS |
Warranty | 5 years |
EAN | 5905555019321 |
Package size (LxWxH) | 13.8x9.4x2.4 in |
Shipping Weight | 2.8 lb |
Type of matrix | IPS |
Display diagonal, inch | 13.3 |
Display resolution, px | 1920x1080 (Full HD) |
Aspect ratio | 16:9 |
Brightness, cd/m² | 400 |
Number of displayed colors | 16.7 m |
Contrast | 1000:1 |
Horizontal/vertical viewing angle, ° | 178/178 |
Size of the visible screen area (WxH), mm | 295x165 |
Pixel pitch (WxH), mm | 0.154x0.154 |
Frequency of optical source, Hz | 60 |
Type of matrix backlight | LED |
LED backlight lifetime, h | 50000 |
Interface | HDMI |
Operating temperature range, °F | 5...+131 |
Operating temperature range, °F | 5...+131 |
Operating humidity range, % | 10 — 90 |
Power supply | AC 110–220V (US type plug adapter is not included), DC 5–12V/1A (Type-C) |
Power consumption, W | 12 (max.) |
