Levenhuk MED 60x Infinity Plan Achromatic Objective

The price is valid only for the online store and may differ from the prices in retail stores.

Infinity-corrected. Spring-loaded frame. Magnification: 40x. Aperture: 0.8

Availability

Product ID	76078
Brand	Levenhuk, Inc., USA
Warranty	2 years
EAN	5905555004792
Package size (LxWxH)	1.2x2.4x1.2 in
Shipping Weight	0.2 lb

Description

The Levenhuk MED 60x infinity plan achromatic objective is an accessory for laboratory infinity-corrected microscopes. It provides 60x magnification, flattens the field of view, eliminates optical aberrations, and allows for observing the microcosm in maximum detail. The objective renders high contrast and sharp images. The Levenhuk MED 60x infinity plan achromatic objective is an instrument for any professional microbiologist.

The objective's lenses are made of glass and housed in the metal body. The front lens features additional protection and a spring-loaded frame.

The kit includes:

Objective
Plastic case

specifications

Product ID	76078
Brand	Levenhuk, Inc., USA
Warranty	2 years
EAN	5905555004792
Package size (LxWxH)	1.2x2.4x1.2 in
Shipping Weight	0.2 lb
Lens material	optical glass
Body material	copper
Objective class by aberration correction degree	plan achromatic
Magnification, x	60
Aperture	0.85
Working distance, mm	0.5
Parfocal distance, mm	45
Cover glass thickness, mm	0.17
Compatible tube length, mm	infinity
Thread type	WJ 4/5"*1/36"
Spring-loaded frame	yes
Immersion	no

References
and downloads

High-resolution images (zip)

(ZIP, 26.42 Mb)

click to
download

Questions and Answers

David (2021.07.16)

Is this objective compatible with the microscope Levenhuk MED 10M? What is its parfocal length?

Customer service:

Dear David, thank you for interest in Levenhuk products. Yes, they are compatible. The parfocal length is 180mm.Is there any additional information you might need?
